COUGAR GR 850W ATX 3.1 Fully Modular Power Supply

Power demanding modern PC builds with the COUGAR GR 850W, a fully modular ATX 3.1 power supply designed for high-performance systems and current-generation graphics hardware.

Featuring 80 PLUS Gold certification, native PCIe 5.1 / 12V-2X6 connectivity, a 105°C Japanese main capacitor, and a compact 140mm chassis, the GR 850 combines powerful output with efficient, flexible installation.

The 850W model also earns Cybenetics Platinum efficiency and A- noise ratings, further distinguishing it within the GR lineup.

Key Features

• 850W Power Output: Provides additional capacity for compatible higher-performance PC configurations.
• ATX 3.1 Compliant: Built to meet the modern ATX 3.1 power supply standard.
• PCIe 5.1 Support: Designed for compatible current-generation graphics hardware.
• Native 12V-2X6 Connector: Provides direct 12+4-pin connectivity for compatible graphics cards.
• 200% Power Excursion Support: Designed to meet ATX 3.1 transient power requirements.
• 80 PLUS Gold Certified: Rated for up to 91% power conversion efficiency.
• Cybenetics Platinum Efficiency Rating: Additional efficiency certification specific to the GR 850W model.
• Cybenetics A- Noise Rating: Acoustic performance certification specific to the 850W model.
• Fully Modular Design: Connect only the cables required by your build for cleaner cable management.
• Single +12V Rail: Delivers up to 70.8A / 849.6W through the +12V rail.
• 105°C Japanese Main Capacitor: Designed for stable, durable power delivery.
• 120mm Rifle-Bearing Fan: Designed to provide efficient cooling while minimizing turbulence and noise.
• 40°C Operating Capability: Designed for reliable performance at ambient temperatures up to 40°C.
• Compact 140mm Length: Helps simplify installation in compatible PC cases.
• Comprehensive Protection: Includes SCP, OCP, OVP, UVP, OPP and OTP.

Fully Modular Cable Design

The GR 850 is fully modular, allowing you to connect only the power cables required for your particular PC.

Fewer unused cables inside the case can simplify installation and make it easier to achieve clean cable management.

Ready for Modern Graphics Cards

The GR 850 supports ATX 3.1 and PCIe 5.1 and includes a native 12V-2X6 (12+4-pin) connector for compatible graphics cards.

COUGAR specifies a 600mm 12V-2X6 cable, providing additional routing flexibility when connecting compatible GPUs.

80 PLUS Gold + Cybenetics Platinum

The GR 850 carries 80 PLUS Gold certification and is rated for up to 91% power conversion efficiency.

The 850W model additionally earns a Cybenetics Platinum efficiency rating, providing another independent efficiency certification beyond 80 PLUS.

Cybenetics A- Noise Rating

The GR 850 also carries a Cybenetics A- noise rating.

Cooling is handled by COUGAR's 120mm rifle-bearing fan, featuring grooved fan blades and an integrated stabilizing ring designed to reduce blade flex and turbulence during operation.

Stable Power Delivery

The GR 850's single +12V rail provides up to 70.8A / 849.6W, supporting the demanding power requirements of compatible modern hardware.

A 105°C Japanese main capacitor is used to support reliable and durable power delivery.

Built-In Protection

The GR 850 includes:

• SCP – Short-Circuit Protection
• OCP – Overcurrent Protection
• OVP – Over Voltage Protection
• UVP – Under Voltage Protection
• OPP – Over Power Protection
• OTP – Over Temperature Protection

Specifications

Why You'll Love It

The COUGAR GR 850W gives higher-performance PC builders additional power capacity without sacrificing the clean installation benefits of a compact, fully modular PSU.

Its combination of 850W output, ATX 3.1, PCIe 5.1, native 12V-2X6 connectivity, 80 PLUS Gold certification, and fully modular cabling makes it a strong option for modern performance-oriented builds.

And unlike the lower-wattage GR models, the 850W also carries Cybenetics Platinum efficiency and A- noise ratings, giving customers additional independently tested efficiency and acoustic credentials.
